With a powerful 50 mw green laser module, the DPSS-50 is a top choice for precision applications. Its 12 mm lens, available in both standard and aspheric options, ensures accurate and efficient laser performance. Each and every Z-Bolt® Class IIIb green laser module ships with laser dimension schematics - length, diameter, designation of + (red) and - (black) leads. Also laser power meter report that includes minimum, maximum and mean power output; power output stability; duration, date and time of testing data. Add an HS-1a Heat Sink and Cooling fan for the moudle, to prevent overheating.
- Standardized 12 mm Size
- 100 mm Wire Leads
- CW Power Output,
- Certified > 50 mW
- Laser Power Meter Reports Included

Each and every Z-Bolt® Class IIIb green laser module ships with laser dimension schematics - length, diameter, designation of + (red) and - (black) leads. Also laser power meter report that includes minimum, maximum and mean power output; power output stability; duration, date and time of testing data. Add an HS-1a Heat Sink and Cooling Fan for extended length operation. Manufactured exclusively for the Z-Bolt® DPSS-50 green laser module units. Helps cool and regulate power output stability during extended length operation.Fan for extended length operation.

Z-Bolt® DPSS-50 Technical Specifications
* Wavelength (Color) - 532 nm (Green)
* Output Power - > 50 mW
* Output Mode - Constant Wave
* Beam Diameter at Source - 1.5 mm
* Beam Divergence - < 1.5mrad
* Diode Circuit Type - ACC
* Optimum Operating Temp - 10C° ~ 35C°
* Operating Voltage - 3VDC
* Current Draw - < 650 mA
* FDA Safety Class - Class IIIb
* Product Warranty - 2 Years
